D41

Titanium Denture Framework Milling Machine

  • 15-inch touch screen
  • Automatic tool changer
  • Accurate 4-axis machining
  • Specially designed milling bur for undercut
  • One-cast steel structure delivers the highest level of stability
  • Top class mechanical & electrical parts
  • Low air pressure protection

Spec Data Sheet Contact Sales for Price
Category:

Additional information

Weight 1500 lbs
Dimensions 120 × 100 × 180 in
Voltage

220V 50Hz; 380V 50Hz (optional)

Power

5.5KW

Spindle Speed

40,000rpm

Precision

< 0.01mm

Number of Bur

7

Cooling Type

Water cooling

Material

Co-cr, Composite Resin, Titanium block, Titanium disc or block

Application

Denture framework, metal crown, pre-milled abutment (optional)

Processing Speed

Denture framework (150 mins/unit), Pre-milled abutment (15 mins/unit), Resin (10 mins/unit), Metal crown (25 mins/unit)
